CASS Test vs Neutral Salt Spray Test: Key Differences and Applications

Corrosion testing is vital to ensuring product quality and longevity across all sorts of industries. At the top of the list for accelerated corrosion testing methods are the Neutral Salt Spray (NSS) Test and the CASS Test (Copper-Accelerated Acetic Acid Salt Spray). While each of these methods simulates corrosive environments to gauge how well materials resist corrosion, they go about it in completely different ways - with big differences too in how aggressive each is and what they're used for.

What is the Neutral Salt Spray (NSS) Test

The Neutral Salt Spray (NSS) Test is the original salt spray test, developed in the 1930s as a standardized way to test corrosion resistance. This method creates a controlled saline environment using a 5% sodium chloride solution atomized at 35°C ± 2°C.

Key Features of NSS Testing

NSS test has a neutral pH between 6.5 and 7.2, simulating marine-like conditions that are similar to coastal environments. The salt spray test machine developed by Presto for NSS testing creates a continuous fog environment where test specimens are exposed for 24 to 1000+ hours depending on the material and required evaluation depth.

Applications of NSS Testing

NSS testing is ideal for:

• Metals and their alloys
• Metallic coatings (anodic and cathodic)
• Conversion coatings
• Anodic oxide coatings
• Organic coatings on metallic materials?

This method is good for quality control and general corrosion resistance testing across industries like automotive, construction and marine.

What is the CASS Test?

The CASS Test is a way more aggressive testing approach than NSS. That's because it's designed to seriously speed up the corrosion process - much, much faster than NSS. The cass test full form is Copper-Accelerated Acetic Acid Salt Spray. This was developed in response to a need for a way to test coatings and specialized surface treatments that truly stood up to the rigors of real-world use.

CASS Test Solution Composition

The CASS Test uses a more complex solution of:

• Standard 5% sodium chloride solution (95 parts water to 5 parts salt by weight)
• 1 gram of copper chloride dihydrate per 4 liters of salt solution
• pH adjustment to 3.1-3.3 using glacial acetic acid
• Operating temperature of 50°C ± 2°C (120°F)

Comparative Analysis: CASS Test vs Neutral Salt Spray Test

Solution and Environmental Differences

The fundamental difference between these methods lies in their solution composition and environmental conditions. While the Neutral Salt Spray Test uses a simple 5% NaCl solution, the CASS Test incorporates copper chloride as an accelerator and maintains an acidic environment.?

Testing Equipment Requirements

Both methods require salt spray test machines, but a CASS tester  needs to handle higher temperatures and more aggressive solutions. Presto’s modern salt spray test machine often combine both capabilities so labs can do multiple test types with the same equipment.?

Results and Interpretation

CASS testing is accelerated, so results come faster than NSS testing. But that comes with trade-offs in real world correlation. NSS results show better correlation with outdoor exposure conditions, CASS provides rapid screening for specific coating types.?

Industry Applications and Standards

• Automotive Industry Applications: The automotive industry uses both methods, CASS is particularly useful for decorative chrome finishes and functional coatings on critical components. NSS is the standard for general corrosion assessment of structural components and body panels.?

• Electronics and Aerospace: Electronic components and aerospace applications require NSS due to better long term environmental exposure correlation. But CASS is useful for rapid qualification of coatings on connectors and specialized components.?

Manufacturing Quality Control

Both methods serve a purpose in manufacturing quality control:

• NSS testing provides corrosion resistance baseline
• CASS testing provides accelerated screening for process control
• Combined testing approaches provide material evaluation?

Equipment Selection and Considerations

Salt Spray Tester Features: Modern salt spray test machines have:

• HMI touchscreen interfaces for precise control
• Programmable temperature and humidity controls
• Automated spray systems with consistent droplet distribution
• Corrosion resistant construction materials
• Data logging for compliance documentation?

CASS Tester Specific Requirements: CASS testers require:

• Enhanced temperature control (up to 50°C)
• Specialized materials to handle acidic solutions
• Copper chloride dosing systems
• pH monitoring and control capabilities?

Testing Standards and Compliance

Both methods have well established international standards:

• ASTM B117: Neutral salt spray testing
• ASTM B368: CASS testing
• ISO 9227: NSS, AASS, CASS methods?

Industries must choose the right testing method based on regulatory requirements and end use applications. Aerospace applications often require NSS for long term correlation, automotive decorative components may require CASS for accelerated testing.?

Cost and Time Considerations

• Cost: NSS testing is generally cheaper to run due to simpler solution preparation and longer equipment life. CASS testing is more expensive to operate but provides faster results to speed up product development and get to market faster.

• Time: CASS testing is ideal for rapid screening applications, 16-48 hours vs weeks for full NSS testing.?

Choosing the Right Corrosion Test for Your Materials

Understanding the difference between CASS Testing and Neutral Salt Spray Testing will help you make informed decisions about your corrosion testing programme. While neutral salt spray testing gives you a long-term correlation that's super applicable to a wide range of uses - which is great - CASS testing gives you a much faster way to figure things out, it's especially useful for things like decorative coatings and specialty jobs. Which test to use will depend on the type of material testing, what you want to use it for, how much time you have to work with, and any regulatory requirements you need to meet.

New salt spray test machines and CASS testers are coming out all the time, always trying to meet industry demand for accuracy, efficiency and making sure they comply with international standards. And to run a successful corrosion testing programme, it's not uncommon for people to use both methods - or at least intend to - so they can get a really good understanding of their materials and get to market sooner without breaking the bank.
