The vibration table is an ergonomically designed product to aid the manufacturers of the paper & packaging industry, mainly from the rigid packaging industry to aid the manufacturers in assessing the ability of their corrugated boxes to withstand tear & damage while in transit by a simulation of the same through the help of this amazing lab testing instrument i.e. the vibration table.
The vibration table design is a result of very thorough manufacturing research & development. The instrument replicates the real-life incidences a corrugated boxes withstand while in transit due to the humps and speed breakers, a storage vehicle carrying corrugated boxes goes by. The replication of such incidences is necessary to secure and safeguard the items (sensitive/insensitive) that will be placed within the boxes.
It is extremely important to understand how a vibration table works to ensure perfect test conduction and achieve accurate results in order to attain the highest level of consumer satisfaction.
Functioning of a Vibration Table
The vibration table manufacturer has made sure to keep the working extremely simplistic for a smooth testing experience thus ensuring precise outputs consistently.
The instrument consists of a platform that measures 1000mm X 1000mm and is constructed for the placement of the specimen and allows the sample to be placed correctly.
The platform is motorized which enables the platform to move into 4 different vibration modes:
1. Vertical synchronous
2. Vertical asynchronous
3. Swivel synchronous
4. Swivel asynchronous
All these 4 movements simulate the movements of a transporting vehicle on altered road conditions or different kinds of speed breakers.
The machine can be adjusted at different angles to ensure the absolute accuracy of the test results:
1. 0 degree
2. 30 degrees
3. 60 degrees
4. 90 degrees
The vibration table manufacturer has designed the vibration amplitude to go up to the height of 25mm (if measured from peak to peak) and the speed of the vibration from 2 Hz to 6 Hz.
All the working and functioning of the instrument is controlled with the help of a digital meter that has feather touch controls for easy handling and single-handed operations along with the provision of a rotary switch which allows the operator to ensure the conduction of the test. The operator-friendly digital meter makes the conduction of the test free of any hassle and allows expeditious testing of samples.
The vibration table along with its easy maneuverability also allows various other features that are necessary to derive precise and accurate results repeatedly.
Features of the Vibration Table
The vibration table price in consideration of its features is very cost-efficient and enables the manufacturer of paper & packaging industries to buy vibration table and avail of such amazing features at a very reasonable cost.
The machine is rigidly fabricated with a material of mild steel coated with a 7-layered powder paint to ensure rustproofing and hence, the durability of the instrument for a longer duration of time.
The tabletop platform is suspended for vibration with the help of various bearing blocks to ensure higher accuracy.
The vibration table design is curated in such a way that the platform of the instrument consists of railings at the edges to ensure precise placement of the specimen and ensure the filled corrugated boxes are tested accurately.
The instrument also offers an intense cast iron base controlled by a dedicated digital panel attached separately from the instrument for long-lasting support.
The frequency variation is an extremely vital feature that the instrument possesses as it allows the operator to measure the ability of the corrugated boxes to withstand humps and breakers on the road at different intensities by adjusting the amplitudes, angles as well as the frequency of the vibration.
The machinery is constructed precisely to determine the effects on the specimen during transportation as well as storage.
The vibration table price is a very cost-efficient feature as well, which enhances the industrial accessibility of the product and allows a major chunk of the manufacturers to comply with the dedicated standards. The machinery is, however, a feature-rich instrument but there are still some factors to be taken care of during the installation of the machinery.
Important Installation Factors to be Taken Care
First and the foremost factor to be adhered to, while installing the instrument is to make sure that the machinery is placed on an even and plane platform to avoid any sort of discrepancies while performing the tasks.
Make sure that the machinery is kept away from other sensitive items or electronic devices while performing the task to safeguard other items from any sort of damage due to the amplified vibration at higher frequencies.
It is also important to make sure that the digital meter is placed close to the vibration table during the performance of the test for better optimization.
Another factor to take care of is to keep the machinery near an electrical socket for a constant supply of electricity and hassle-free test conduction.
Feel free to learn more about the installation methods & vibration table cost from the vibration table supplier.
Conclusion
The vibration table is a very well-designed lab testing instrument enabling the manufacturers from the paper & packaging industry to measure the ability of corrugated boxes to withstand travel hassles by replicating real-life travel vibration frequencies and amplifications. The machinery operates on different modes to deliver the exact results for a better assessment.
The vibration table price also makes the instrument very cost-efficient for the features it has to offer. The machinery with advanced technology safeguards the sensitive items kept inside the corrugated boxes.
Buy Vibration Table Today
To attain more knowledge regarding the vibration table cost or regarding the manufacturer & vibration table supplier, you can feel free to visit our website or also contact us via phone at +91 9210903903 or write to us via e-mail at info@prestogroup.com. We are delighted to serve our customers and offer them the finest lab testing products available in the market. Buy a vibration table today.
