How Presto Cyclic Test Chamber Helps in Testing Longevity and Durability of Products?

How Presto Cyclic Test Chamber Helps in Testing Longevity and Durability of Products?

Cyclic Test Chamber

Are you continuously facing the challenge of poor durability of materials against wetting/condensation? Are your metal products not able to perform well in salt-laden environments? If yes, then it is important for you to test the products accurately against corrosion. This can be done with the help of the right lab testing instrument known as a cyclic test chamber – CYKOThis is one of the high-quality lab testing equipment that is used to test the corrosion resistance properties of surface coatings of different materials.

This highly standardized lab testing equipment can accurately perform different types of tests like neutral salt spray tests, salt spray and wetting/condensation humidity (SWAAT) or salt spray and air drying (PROHESION) tests. In this blog, we will discuss a brief about the Presto salt spray testing instrument CYKO model and its highly advanced features. We will also discuss why it is important to test the corrosion-resistance properties of the materials.

Introduction to Presto Cyclic Test Chamber- CYKO

Metals are commonly used in various industries and applications due to their desirable properties such as strength, conductivity, and durability. However, one major concern when using metals is their vulnerability to corrosion. This will not only lead to product damage but also lead to high product rejection rates.

Thus, we at Presto have designed a high-quality lab testing instrument known as a cyclic test chamber-CYKO that is used to test the corrosion resistance properties of the materials and ensure that quality materials will be delivered to the customers.

This quality testing equipment has been designed as per industry standards that include ASTM B117, JIS Z 2371, ISO 9227, and various international test standards. This will ensure accuracy in testing results.

Now, let us discuss the features of Presto cyclic test chamber-CYKO.

Features of Presto cyclic test chamber-CYKO

The Presto Cyclic Corrosion Salt Spray Chamber is a true game-changer in the world of corrosion testing. With its innovative design and unparalleled versatility, this system offers an interactive and comprehensive approach to simulating real-world environmental conditions that can cause corrosion.

Below we have listed the features of this high-quality lab testing instrument.

  • HMI-based Touchscreen Model

  • Relative Humidity can be monitored on HMI Screen.

  • Cyclic Test mode enabled setting parameters according to the test sample

  • Corrosion Resistant PT-100 sensor

  • Solid-state digital Programmable Temperature Controller

  • Program profile for selecting test parameters and performing the test.

  • Easy Data Management. Users can create PID settings, Air Saturator settings, test temperature, test and air purge time etc.

  • Current test running status display

  • Robust Construction with Fiber reinforced body (Triple wall)

  • Ease of use of sample placements inside the test chamber

  • Pneumatically operated canopy

  • Air purge after the test for fog settlement.

  • Reservoir Tank inside sponge filter with low solution level alarm.

  • 5 point Auto Tuning feature selection

  • Real-time vs temperature graph

  • Data recording with a temperature data reading

  • USB option available (Pen drive is not a part of supply)

  • User can control PID settings through Advanced Hysteresis setting

  • Angle of Canopy maintained in order to restrict the flow of droplets directly on the test sample.

Technical specifications of Presto cyclic test chamber:

  • Display: HMI Based touchscreen 7" TFT LCD Color screen

  • Cyclic Corrosion Chamber 450 Ltr. : Internal size: 1000x700x750 mm

  • Humidity (RH Range): Fixed at 95% - 100 % RH ±5%

  • Humidity Temperature Range: 40 to 50 ºC ±3ºC (90% above relative humidity)

  • Dry Cycle Temperature Range: 5 above Amb. to 60 ºC ±3ºC

  • Salt Cycle Temperature Range: 5 above Amb. to 35 ºC ±2ºC

  • Chamber Temperature Least Count: 0.1ºC

  • Air Saturator Temperature Range: 40ºC- 55ºC

  • Air Saturator Temperature Least Count: 0.1ºC

  • Air Saturator Temperature Repeatability: ± 2ºC

  • Power: 220, Single phase, 50 Hz, 15 A

  • pH value of Salt Solution: 6.5 to 7.2 pH

  • Temperature Control: Inbuilt PID Temperature Controller

  • Timer(Hour meter): 6 digits

  • Test Air Pressure: 0.7Kg/cm² - 1.2Kg/cm²

  • Air Regulator: 0 to 30 psi

  • NaCl Solution Tank Capacity: 60 Ltr.

  • Compressed Air requirement: Approx. 7 cfm (Air Compressor not part of supply) Main airline pressure regulator with filter in customer scope.

With these high-end features and technical specifications, one can easily evaluate the corrosion resistance of materials with ease. To know the salt spray chamber priceand discounts or want a virtual tour of this lab testing equipment, give us a call at +91-9210903903 or email us at info@prestogroup.com. Our team of technical experts will consult you regarding all your queries.
